CP8848

1/2" Impact Wrench

1/2 Inch	50-700 ft. 68 - 950 Nm	775 ft. lb 1,050 Nm	1,900	6.9 lb 3.1 kg	Reduced Vibration	Charge Gauge

Powerful and Efficient ½" anvil with ring retainer Max. torque: 775 ft.lb/1,050 Nm in reverse 6.9 lb/3.1 kg 9.5 in/243 mm length 20-Volt CP20XP Lithium-Ion 4Ah battery Power Max. torque: 775 ft.lb/1,050 Nm in reverse 1,900 RPM Performance Full metal gearbox and helical gears Torque reaction part in aluminum Runtime: CP20XP Battery 4Ah battery 20-Volt Lithium-ion Charge gauge Rubber battery dampeners absorb impacts and shocks

Durability Aluminum back and clutch housing Convenience Single-hand forward/reverse operation Full teasing trigger Safety lock position Comfort Ergonomic handle fits your hand perfectly Thermo Plastic Rubber (TPR) over molded handle Resistance to Shocks Specific composite housing in rubber elastomer material Four composite bumpers for protection in two directions Overmold on top Replaceable side bumpers

CP8848	Part Number	Drive	Free Speed	Max Torque in Reverse		Working Torque		Weight with Battery		Weight w/o Battery		Length		Height		Width		Sound Level	Sound Power	Vibration	Battery
		in	RPM	ft. lb	Nm	ft. lb	Nm	lb	kg	lb	kg	in	mm	in	mm	in	mm	dB(A)	dB(A)	m/s2-k	V	Ah
20V ½" IMPACT WRENCH BARE TOOL	8941088489	1/2 with ring retainer	1,900	775	1,050	50 - 700	68 - 950	6.94	3.15	5.35	2.43	9.5	243	9.88	251	3.18	81	89	100	12.2 (2.3)	20	4
20V ½" IMPACT WRENCH PACK*	8941088480
20V ½" IMPACT WRENCH PACK US*	8941088481

Sound and vibration values are according to noise and vibration statement (EN60745).
* Tool packs come with 2 batteries and 1 charger. Extra individual batteries and chargers are available

CP8848-2 2" Anvil	Part Number	Drive	Free Speed	Max Torque in Reverse		Working Torque		Weight with Battery		Weight w/o Battery		Length		Height		Width		Sound Level	Sound Power	Vibration	Battery
		in	RPM	ft. lb	Nm	ft. lb	Nm	lb	kg	lb	kg	in	mm	in	mm	in	mm	dB(A)	dB(A)	m/s2-k	V	Ah
20V ½" IMPACT WRENCH BARE TOOL	8941088488	1/2 with ring retainer 2" extended anvil	1,900	775	1,050	50 - 700	68 - 950	7.38	3.35	5.79	2.63	11.5	291	9.88	251	3.18	81	89	100	12.2 (2.3)	20	4
20V ½" IMPACT WRENCH PACK*	8941088482
20V ½" IMPACT WRENCH PACK US*	8941088483

Sound and vibration values are according to noise and vibration statement (EN60745). All values are current as of the date of this publication.
* Tool packs come with 2 batteries and 1 charger. Extra individual batteries and chargers are available.

CP8828

3/8" Impact Wrench

Compact and Versatile

• ⅜" anvil with ring retainer
• Max. torque: 150 ft.lb/205 Nm in reverse
• 4 lb/1.8 kg
• 6.1 in/152 mm length
• 20-Volt CP20XP Lithium-ion 4Ah battery

3/8 Inch	150 ft. lb 205 Nm	2,400	4lb 1.8 kg	Reduced Vibration	LED Lit	Charge Gauge

Great Power/Weight Ratio

• Max. torque: 150 ft.lb/205 Nm in reverse
• 2,400 RPM
• Frameless motor

Run Time: CP20CP Battery

• 4Ah battery
• 20-Volt Lithium-ion
• Charge gauge
• Rubber battery dampeners absorb impacts and shocks

Durability

• Aluminum clutch housing

Convenience

• LED lighting for dimly lit work areas
• Single-hand forward/reverse operation
• Full teasing trigger
• Safety lock position

Comfort

• Ergonomic handle fits your hand perfectly
• Thermo Plastic Rubber (TPR) over molded handle

CP8828	Part Number	Drive	Free Speed	Max Torque in Reverse		Weight with Battery		Weight w/o Battery		Length		Height		Width		Sound Level	Sound Power	Vibration	Battery
		in	RPM	ft. lb	Nm	lb	kg	lb	kg	in	mm	in	mm	in	mm	dB(A)	dB(A)	m/s2-k	V	Ah
20V ⅜" IMPACT WRENCH BARE TOOL	8941088289	3/8 with ring retainer	2,400	150	205	3.99	1.81	2.38	1.08	6.1	152	9.27	237.5	2.3	58.4	89.5	100.5	2.5 (1.5)	20	4
20V ⅜" IMPACT WRENCH PACK*	8941088280
20V ⅜" IMPACT WRENCH PACK US*	8941088281

Sound and vibration values are according to noise and vibration statement (EN60745). All values are current as of the date of this publication.
* Tool packs come with 2 batteries and 1 charger. Extra individual batteries and chargers are available.
